DFX12025 Skeleton Centrifugal Fan

  • 120 mm cooler

High quality industrial cooling fan 12025, airstream vane-axial fan

Contact us

Specifications of DFX12025 Skeleton Centrifugal Fan

ListedRatedOperatingRated CurrentRated SpeedAirStaticNoiseAvailable Features (Optional)Weight
ModelVoltageVoltageFlowpressureLevel

(VDC)(VDC)(A)(RPM)(CFM)(mmH2O)(dBA)



g
TachometerRotationThermalPulse Width
OutputDetectorControlModulation
DFX122512H126.0~13.80.352,50072.403.3034.6076
DFX122512M6.0~13.80.252,30066.602.8032.50
DFX122512L6.0~13.80.202,10060.802.3030.10
DFX122524H2412.0~27.60.222,50072.403.3034.60
DFX122524M12.0~27.60.172,30066.602.8032.50
DFX122524L12.0~27.60.152,10060.802.3030.10
X=S: Sleeve Bearing or B: Ball Bearing or H: Hydro Bearing; Specifications are subject to change without notice


Description of DFX12025 Skeleton Centrifugal Fan

  • Frame: PBT OF UL 94V-0

  • Impeller: PBT OF UL 94V-0

  • Bearing Type: Sleeve Bearing &  Ball Bearing& Hydro Bearing

  • Lead Wires: UL Type or Equivalent ( + ) : Red ( - ) : Black

  • Motor Protection: Reverse Polarity Protected;  Automatic Restart

  • Operating Temperature and Humidity: -10℃~70℃,5%~90%RH

  • Storage Temperature and Humidity: -40℃~80℃,5%~95%RH



Description of DFX12025 Skeleton Centrifugal Fan


Description of DFX12025 Skeleton Centrifugal Fan


Still not find the solutions for your cooling and airflow system, Contact Xie Heng Da axial cooling fan manufacturer for custom 120mm computer case fan.
