Specifications of DFX5015 Wide Mouthed DC Blower Fan
| Listed | Rated | Operating | Rated Current | Rated Speed | Air | Static | Noise | Available Features (Optional) | Weight | |||
| Model | Voltage | Voltage | Flow | pressure | Level | |||||||
| （VDC） | （VDC） | （A） | （RPM） | （CFM） | (mmH2O) | (dBA) | g | |||||
| Tachometer | Rotation | Thermal | Pulse Width | |||||||||
| Output | Detector | Control | Modulation | |||||||||
| DFX501505H | 5 | 3.5~5.75 | 0.35 | 4,500 | 4.10 | 14.40 | 37.20 | ◆ | ◆ | ◆ | 23 | |
| DFX501505M | 3.5~5.75 | 0.25 | 4,000 | 3.60 | 11.40 | 34.10 | ◆ | ◆ | ◆ | |||
| DFX501505L | 3.5~5.75 | 0.15 | 3,000 | 2.70 | 6.40 | 26.60 | ◆ | ◆ | ◆ | |||
| DFX501512H | 12 | 6.0~13.8 | 0.20 | 4,500 | 4.10 | 14.40 | 37.20 | ◆ | ◆ | ◆ | ||
| DFX501512M | 6.0~13.8 | 0.15 | 4,000 | 3.60 | 11.40 | 34.10 | ◆ | ◆ | ◆ | |||
| DFX501512L | 6.0~13.8 | 0.10 | 3,000 | 2.70 | 6.40 | 26.60 | ◆ | ◆ | ◆ | |||
| DFX501524H | 24 | 12.0~27.6 | 0.15 | 4,500 | 4.10 | 14.40 | 37.20 | ◆ | ◆ | ◆ | ||
| DFX501524M | 12.0~27.6 | 0.10 | 4,000 | 3.60 | 11.40 | 34.10 | ◆ | ◆ | ◆ | |||
| DFX501524L | 12.0~27.6 | 0.06 | 3,000 | 2.70 | 6.40 | 26.60 | ◆ | ◆ | ◆ | |||
| X=S: Sleeve Bearing or B: Ball Bearing or H: Hydro Bearing; Specifications are subject to change without notice | ||||||||||||
Description of DFX5015 Wide Mouthed DC Blower Fan
Frame: PBT OF UL 94V-0
Impeller: PBT OF UL 94V-0
Bearing Type: Sleeve Bearing / Ball Bearing / Hydro Bearing
Lead Wires: UL Type or Equivalent ( + ) : Red ( - ) : Black
Motor Protection: Reverse Polarity Protected; Automatic Restart
Operating Temperature and Humidity: -10℃～70℃,5%～90%RH
Storage Temperature and Humidity: -40℃～80℃,5%～95%RH
Xie Heng Da bulk 50mm blower fan 24v offer diverse technical recommendations to our clients, catering to their specific needs.
+
+
+
