Specifications of DFX12038 Booster Fan
| Listed Model | Rated Voltage | Operating Voltage | Rated Current | Rated Speed | Air Flow | Static pressure | Noise Level | Available Features (Optional) | Weight | |||
| （VDC） | （VDC） | （A） | （RPM） | （CFM） | (mmH2O) | (dBA) | Tachometer Output | Rotation Detector | Thermal Control | Pulse Width Modulation | g | |
| DGX123812D | 12 | 6.0~13.8 | 3.00 | 6,000 | 213.00 | 29.50 | 61.50 | ◆ | ◆ | ◆ | ◆ | 304 |
| DGX123812H | 6.0~13.8 | 1.50 | 5,000 | 177.50 | 20.50 | 56.80 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123812M | 6.0~13.8 | 0.70 | 4,000 | 142.00 | 13.10 | 51.00 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123812L | 6.0~13.8 | 0.40 | 3,000 | 106.50 | 7.40 | 43.50 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123824D | 24 | 12.0~27.6 | 1.20 | 6,000 | 213.00 | 29.50 | 61.50 | ◆ | ◆ | ◆ | ◆ | |
| DGX123824H | 12.0~27.6 | 0.80 | 5,000 | 177.50 | 20.50 | 56.80 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123824M | 12.0~27.6 | 0.40 | 4,000 | 142.00 | 13.10 | 51.00 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123824L | 12.0~27.6 | 0.20 | 3,000 | 106.50 | 7.40 | 43.50 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123848D | 48 | 28.0~56.0 | 0.70 | 6,000 | 213.00 | 29.50 | 61.50 | ◆ | ◆ | ◆ | ◆ | |
| DGX123848H | 28.0~56.0 | 0.40 | 5,000 | 177.50 | 20.50 | 56.80 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123848M | 28.0~56.0 | 0.20 | 4,000 | 142.00 | 13.10 | 51.00 | ◆ | ◆ | ◆ | ◆ | ||
| DGX123848L | 28.0~56.0 | 0.12 | 3,000 | 106.50 | 7.40 | 43.50 | ◆ | ◆ | ◆ | ◆ | ||
| X=S: Sleeve Bearing or B: Ball Bearing or H: Hydro Bearing; Specifications are subject to change without notice | ||||||||||||
Description of DFX12038 Booster Fan
Frame: PBT OF UL 94V-0
Impeller: PBT OF UL 94V-0
Bearing Type: Sleeve Bearing / Ball Bearing
Lead Wires: UL Type or Equivalent ( + ) : Red ( - ) : Black
Motor Protection: Reverse Polarity Protected; Automatic Restart
Operating Temperature and Humidity: -10℃～70℃,5%～90%RH
Storage Temperature and Humidity: -40℃～80℃,5%～95%RH
Xie Heng Da axial cooling fan factory provide 120mm cooling fan, effective cooling and optimized airflow solutions.
+
+
+
